Metal spacers from 8 cm to large 150 cm.
Our spacers are made of rolled steel with non-cutting edges.
Our spacers are made of laminated steel with round and non-cutting edges that guarantee a tensile strength of 70kg./mm. Available in packs of 100 pieces packaged in high strength thermoset welded polyethylene bags.
• use one-piece spacers
• carefully check the correct connection between the uprights and the feathers;
• use the same type of equipment in the construction of a wall (eg u-shaped upright or elecoidal upright and small feathers with large feathers);
• make sure they are used in an appropriate number of spacers depending on the wall you need to make;
• the concrete must be poured slowly, not to pour the concrete suddenly, especially at the base of the formwork
(the maximum vertical filling speed is 2.5 meters / hour).
Our spacers are of laminated steel with round and non-cutting edges that guarantee a tensile strength of 70kg / mm. Available in packs of 100 pieces packaged in high-resistance thermoset polyethylene bags.
10 cm.
15 cm.
20 cm.
25 cm.
30 cm.
35 cm.
40 cm.
45 cm.
50 cm.
On request we can produce any size larger than 120 cm.
| WIDTH WALL CM | HIGH WALL CM | LENGTH WALL CM | DISTANCE BETWEEN IN CM |
| 10 – 20 | 150 – 250 | 150– 500 | 35 |
| 10 – 20 | 150 – 250 | >500 | 45 |
| 10 – 20 | 300 – 500 | 150 – 500 | 30 |
| 10 – 20 | 300 – 500 | >500 | 35 |
| LATIME PERETE CM | HIGH WALL CM | LENGTH WALL CM | DISTANCE BETWEEN IN CM |
| 25 – 40 | 150 – 250 | 150 – 500 | 30 |
| 25 – 40 | 150 – 250 | >500 | 35 |
| 25 – 40 | 300 – 400 | 150 – 500 | 30 |
| 25 – 40 | 300 – 400 | >500 | 35 |
| 25 – 40 | 400 – 500 | 150 – 500 | 30 |
| 25 – 40 | 500 – 600 | >500 | 25 |
| LATIME PERETE CM | HIGH WALL CM | LENGTH WALL CM | DISTANCE BETWEEN IN CM |
| 45 – 60 | 100 – 250 | 150 – 300 | 25 |
| 45 – 60 | 100 – 250 | >300 | 30 |
| 45 – 60 | 300 – 400 | 150 – 300 | 25 |
| 45 – 60 | 400 – 500 | >300 | 30 |
| 45 – 60 | 500 – 600 | >300 | 25 |
| 70 – 100 | 100 – 200 | >300 | 30 |
